DEK HORIZON 03IX SMT Paste Printer - Precision Stencil Printing for PCB Assembly & Quality Control

DEK HORIZON 03IX SMT Paste Printer - Precision Stencil Printing for PCB Assembly & Quality Control Specification

Product Type
SMT Paste Printer

Material
Steel, Aluminium Alloy, High-durability Industrial Components

Capacity
Up to 8,000 PCB assemblies per hour

Computerized
Yes

Automatic Grade
Fully Automatic

Control System
Windows-based Touchscreen GUI, Integrated Vision Alignment

Processing Type
Precision Stencil Printing for PCB Assembly

Voltage
220-240V AC, 50/60 Hz

Power
Max 2.6 kW

Dimension (L*W*H)
1800 mm 1400 mm 1500 mm

Weight
Approx. 1,600 kg

Color
Industrial Grey/Blue

Cycle Time (Typical)
< 10 seconds (excluding board loading/unloading)

Max PCB Size
510 mm x 508 mm

Stencil Frame Size Supported
300 mm x 300 mm to 736 mm x 736 mm

Repeatability
2 m

Paste Inspection
2D and 3D SPI Compatibility (Optional)

Squeegee Type
Pneumatic/Adjustable Angle, Metal Blade

Vision Alignment
High-Resolution Dual Camera Fiducial Recognition

Data Interface
Ethernet, USB, SMEMA Interface

PCB Thickness Range
0.4 mm to 6 mm

Standard Features
Auto Cleaning System, Programmable Squeegee Pressure, Automatic Stencil Positioning

Min PCB Size
50 mm x 50 mm

Printing Accuracy
12.5 m @ 6 sigma, Cpk 2

DEK HORIZON 03IX SMT Paste Printer - Precision Stencil Printing for PCB Assembly & Quality Control Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
20 Units Per Month

Delivery Time
30 Days

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

About DEK HORIZON 03IX SMT Paste Printer - Precision Stencil Printing for PCB Assembly & Quality Control

Prices are for show only, please contact us for exact price.

Product Description

The DEK HORIZON 03IX SMT Paste Printer is a high-performance solution designed for precision stencil printing in PCB assembly processes. Engineered to meet the demands of modern electronics manufacturing, this printer delivers consistent and accurate solder paste deposition, ensuring optimal quality control for both high-mix and high-volume production environments. Equipped with advanced vision alignment systems and automated calibration, the HORIZON 03IX minimizes errors and maximizes throughput, making it ideal for industries such as automotive, telecommunications, and consumer electronics. Its user-friendly interface and flexible configuration options streamline setup and operation, reducing downtime and enhancing productivity. Whether you're working with fine-pitch components or complex PCB designs, the DEK HORIZON 03IX ensures reliable performance and exceptional print quality. By integrating robust quality control features, this SMT paste printer helps manufacturers maintain high standards while reducing waste and rework. For businesses seeking to optimize their SMT production lines, the DEK HORIZON 03IX offers the precision, efficiency, and reliability needed to stay competitive in today's fast-paced manufacturing landscape

Product Specifications

Model (03i,02i,03IX)	Horizon 03iX
Serials
Vintage	2013 / 2014
Pressure feedback hardware	Option
Board foil clamp size (250/340/520)	520MM/250MM
Screen cleaner type(Cyclone,blue, vortex)	Blue under screen cleaner
Camera type (hawkeye 750)	Hawkeye 750
camera type (hawkeye1700 )	Option
Max Print Area	510x508mm
Operating System	Win XP+09sp13 or up
Tooling	Magnetic tooling pins /option vacuum and grid-lock
Transport System Type	Front Rail Fixed and board clamp or option
Transport System Direction	System setup
PCB thickness	0.2-6MM
Substrate Weight	0-1kg
Screen Frame Size	736x736
Voltage	AC 220V 50-60Hz
voltage AC110v	Option
Machine weight	700Kg
Machine Size	L1400xD1800xH1500mm
Spueegee	Anysize one set
Print Modes	Standard Print head
Machine Alignment Capability	2.0@25microns
620MM longboard screen cleaner	Option
Heavy board Transport line	Option
cyclone screen cleaner 500/400/300mm	Option
Auto solder past dispenser	Option
Software options
Basic board inspection	Option
Vision Plus - hawkeye	Option
Advanced board inspection	Option
Advanced Stencil Inspection	Option
LongBoard 620mm	Option
Automatic Fiducial Setup	yes
QC CALC	option
Small Fiducial	yes
Net working	yes
Auto Stencil screen loader	Option
Hawkeye bridge	Option
Diposit verification	Option
FAST PRINT SPEED	YES
PRO DEK	Option
SPEED UP	Option
GEM/SECS	Option

High Precision for Optimal Solder Paste Printing

Equipped with advanced vision alignment and a tight repeatability of 2 m, the DEK HORIZON 03IX delivers consistent printing results with exceptional accuracy. The machine's ability to maintain a 12.5 m accuracy at 6 sigma ensures minimal defects and reliable performance, essential for high-volume PCB manufacturing environments where quality cannot be compromised.

Comprehensive Automation for Enhanced Productivity

This fully automatic paste printer features programmable squeegee pressure, automatic stencil positioning, and an auto cleaning system for uninterrupted production. The intuitive Windows-based touchscreen GUI simplifies setup and control, allowing operators to maximize throughput with cycle times under 10 seconds (board handling excluded). Smart process integration increases efficiency and reduces downtime.

Wide Compatibility and Robust Construction

Supporting a broad range of PCB and stencil frame sizes and accommodating varying PCB thicknesses (0.4 mm to 6 mm), the DEK HORIZON 03IX offers flexibility for diverse production needs. Built from industrial-grade steel and aluminium alloy, the machine is engineered for durability, heavy-duty use, and consistent operation in demanding factory environments.

FAQ's of DEK HORIZON 03IX SMT Paste Printer - Precision Stencil Printing for PCB Assembly & Quality Control:

Q: How does the DEK HORIZON 03IX achieve such high printing accuracy for PCB assembly?

A: The DEK HORIZON 03IX utilizes a high-resolution dual camera fiducial recognition system for vision alignment, combined with precise mechanical engineering to achieve a printing accuracy of 12.5 m at 6 sigma. This ensures consistent, repeatable paste application even on complex or miniaturized PCB designs.

Q: What types and sizes of PCBs and stencil frames can this printer accommodate?

A: This SMT paste printer supports PCB sizes ranging from 50 mm x 50 mm up to 510 mm x 508 mm and PCB thicknesses from 0.4 mm to 6 mm. It is compatible with stencil frames measuring between 300 mm x 300 mm and 736 mm x 736 mm, offering flexibility for various manufacturing requirements.

Q: When should I consider using the 2D or 3D SPI compatibility option?

A: Opt for the 2D or 3D Solder Paste Inspection (SPI) compatibility if your process demands thorough inspection and quality assurance of solder paste deposits immediately after printing. This feature helps proactively detect and prevent defects, especially in high-reliability electronics manufacturing.

Q: Where can the DEK HORIZON 03IX be installed, and what are its power requirements?

A: This machine is suitable for installation in industrial production environments and advanced assembly lines. It operates on 220-240V AC, 50/60 Hz power supply and requires adequate floor space (1,800 mm x 1,400 mm x 1,500 mm) to accommodate its robust structure.

Q: What is the process for automatic cleaning and stencil positioning?

A: The DEK HORIZON 03IX features an auto cleaning system that maintains stencil cleanliness between cycles, enhancing print quality and reducing manual intervention. Its automatic stencil positioning aligns the stencil precisely before each print, minimizing setup time and ensuring repeatability.

Q: How can users control and monitor the printing process?

A: Operators interact with the printer via a Windows-based touchscreen GUI, allowing for straightforward programming of print parameters such as squeegee pressure and stencil position. Ethernet, USB, and SMEMA interfaces enable integration with line management systems for centralized control and monitoring.

Q: What are the main benefits of using the DEK HORIZON 03IX in a production setting?

A: This SMT paste printer offers rapid processing (up to 8,000 PCB assemblies per hour), exceptionally high accuracy, and robust automation features. These advantages translate into increased productivity, reduced labor requirements, consistent solder paste application, and improved final product quality.
