YAMAHA YG200 High Speed Chip Mounter Precision Surface Mount Technology for Efficient PCB Assembly

YAMAHA YG200 High Speed Chip Mounter Precision Surface Mount Technology for Efficient PCB Assembly Specification

Product Type
High-Speed Chip Mounter

Material
Steel, Aluminum Alloy

Capacity
Up to 0.17 sec/chip; ~36,000 CPH

Computerized
Yes

Automatic Grade
Automatic

Control System
Industrial PC with Touch Panel

Processing Type
Precision SMT Placement

Voltage
AC 200V, 3-phase, 50/60Hz

Power
4.5 kVA

Dimension (L*W*H)
1,875 mm 2,650 mm 1,445 mm

Weight
Approx. 1,900 kg

Color
White / Blue

Applicable PCB Size
Min 50 x 50 mm, Max 510 x 460 mm

Vision System
High-speed recognition system

Component Range
0402 (01005) to 32 mm square

Placement Method
On-the-fly centering

Noise Level
Less than 75 dB(A)

Nozzle Heads
8 heads

Mounting Accuracy
0.05 mm (chip), 0.03 mm (IC)

Network Capability
Supported

Feeder Capacity
Up to 120 units

Air Supply
0.5 MPa, 400 L/min (ANR)

Production Modes
High-mix, high-volume

PCB Conveying System
Automatic width adjustment

Model
YG200

Operating Temperature
15C to 35C

Operation Interface
User-friendly color LCD

YAMAHA YG200 High Speed Chip Mounter Precision Surface Mount Technology for Efficient PCB Assembly Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
20 Units Per Month

Delivery Time
30 Days

Main Export Market(s)
Central America, Asia, Australia, South America, North America, Eastern Europe, Western Europe, Middle East, Africa

About YAMAHA YG200 High Speed Chip Mounter Precision Surface Mount Technology for Efficient PCB Assembly

Prices are for show only, please contact us for exact price.

Product Description

The YAMAHA YG200 high-speed chip mounter is engineered for precision and efficiency in Surface Mount Technology (SMT) applications. Designed to provide rapid, accurate placement of a wide range of components, from small chips to complex devices, the YG200 excels in high-speed, high-volume production environments. Its advanced vision systems and automated feeder options ensure seamless integration into diverse production lines, improving throughput and reducing error rates. The YG200 is built to handle intricate components with exceptional placement accuracy, making it ideal for industries such as electronics, automotive, and telecommunications. With its intuitive interface and minimal setup time, the YAMAHA YG200 enhances productivity while maintaining high standards of quality. Whether you're working in high-mix or high-volume settings, this chip mounter offers the reliability and performance you need for efficient PCB assembly

Product Specifications

Machine Model	YG200
Vintage
Machinie Head	? beam x ? nozzles
Applicable PCB	L330 (420mm) xW250mm to L50xW50mm
Through-put (Optimum)	0.08sec/CHIP
Mounting accuracy (Yamaha's standard components)
Applicable components	0402mm to 14mm IC, CSPs, QFPs
Feeder base	Front and rear feeder base
Number of component types	80 types(Max, 8mm tape reel conversion)
Power supply	3-Phase AC 380V, 4.0Kw
External dimension*2	L1,950W1,408H1,450mm
Weight	Approx. 2,080kg

Precision and Speed for Advanced PCB Assembly

Benefit from industry-leading speed and accuracy with the YAMAHA YG200, designed to handle up to 36,000 components per hour. Its high-speed recognition vision system ensures reliable component placement with up to 0.03 mm accuracy, making it perfect for applications requiring meticulous precision in electronic manufacturing.

Flexible and User-Centric Operation

The YG200 boasts remarkable versatility, accommodating a wide component range and PCB sizes from 50 x 50 mm to 510 x 460 mm. Featuring automatic width adjustment and an intuitive color LCD touch panel, operators can easily manage settings and tasks, streamlining workflows across changing production requirements.

Robust Build and Seamless Connectivity

Constructed from durable steel and aluminum alloy, the YG200 is built for heavy-duty operation. It offers comprehensive network capabilities and a computerized control system, ensuring seamless integration into modern factory settings and supporting a variety of production modes for efficiency and convenience.

FAQ's of YAMAHA YG200 High Speed Chip Mounter Precision Surface Mount Technology for Efficient PCB Assembly:

Q: How does the YAMAHA YG200 ensure precise component placement?

A: The YAMAHA YG200 utilizes a high-speed vision recognition system and on-the-fly centering technology for component alignment, achieving placement accuracies of 0.05 mm for chips and 0.03 mm for ICs. This combination enables high reliability and precision during the assembly process.

Q: What types of components and PCB sizes can the YG200 handle?

A: This chip mounter supports components ranging from 0402 (01005) up to 32 mm square. PCB sizes can vary from a minimum of 50 x 50 mm to a maximum of 510 x 460 mm, making it suitable for a broad spectrum of PCB assembly applications.

Q: When is the ideal use case for the YG200's high-mix, high-volume production mode?

A: The high-mix, high-volume mode is ideal when manufacturers need to assemble various PCB types and batch sizes in a single operation. This is especially beneficial for companies producing a diverse range of electronics requiring frequent changeovers and consistent throughput.

Q: Where can the YG200 be installed for optimal performance?

A: The YG200 operates best in environments maintained at 15C to 35C with a noise level below 75 dB(A). Its robust build and compact design make it suitable for electronic manufacturing facilities, whether as a standalone unit or integrated into an automated assembly line.

Q: What is the standard process for assembling PCBs with the YG200?

A: PCB assembly with the YG200 involves loading feeder units, configuring parameters via the touch panel, and allowing the machine's automatic width adjustment and on-the-fly centering to mount components. The built-in vision system continually checks placement accuracy throughout the process.

Q: How does the user interface enhance the operation of the YG200?

A: The user-friendly color LCD touch panel simplifies setup, parameter input, and operation monitoring. It helps operators efficiently manage production runs, troubleshoot issues, and switch quickly between different PCB assembly tasks.

Q: What are the main benefits of using the YG200 for PCB assembly?

A: Employing the YG200 offers manufacturers heightened assembly speed, superior mounting precision, versatile compatibility with different PCBs and components, and streamlined control via its computerized interface. These features collectively increase productivity, product quality, and operational efficiency.
