YAMAHA YSM10 SMT Mounter with ATS High Precision Surface Mount Technology for Efficient PCB Assembly

YAMAHA YSM10 SMT Mounter with ATS High Precision Surface Mount Technology for Efficient PCB Assembly Specification

Product Type
SMT Mounter

Material
High-precision steel and industrial-grade composites

Capacity
Up to 46,000 CPH (optimum conditions)

Computerized
Yes

Automatic Grade
Automatic

Control System
Advanced ATS (Auto Tray Sequencer), touch panel interface

Processing Type
Surface Mount Technology (SMT)

Voltage
AC 200-240V, 3-phase

Power
Approx. 3.5 kVA

Dimension (L*W*H)
1,254 mm x 1,695 mm x 1,445 mm

Weight
Approx. 1,300 kg

Color
Light Grey / Blue

Software
Yamaha original user-friendly operation software, Error Traceback, Production Analysis

PCB Size Supported
Max: 810 x 490 mm / Min: 50 x 50 mm

Relative Humidity
30% to 70% RH (non-condensing)

Mountable Components
Chips, ICs, large connectors, odd-shaped components

Vision System
Advanced alignment and inspection with camera-based recognition

Component Range
0402 (01005) to 45 x 100 mm, height up to 15 mm

Placement Accuracy
0.035 mm/Chip (Cpk 1.0)

Safety Features
Emergency stop switch, Interlock system, Safety covers

Component Recognition
High-speed Multi-Vision System

Noise Level
75 dB

Network Compatibility
SMEMA/IPC interface support, MES integration ready

Operation Temperature
5C to 40C

Conveyor
Flexible PCB entry for seamless inline production

Head Type
Single Gantry with 1-Beam, 10-Nozzle Head

Feeder Capacity
Up to 120 feeders

YAMAHA YSM10 SMT Mounter with ATS High Precision Surface Mount Technology for Efficient PCB Assembly Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
20 Units Per Month

Delivery Time
30 Days

Main Export Market(s)
Africa, Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East

About YAMAHA YSM10 SMT Mounter with ATS High Precision Surface Mount Technology for Efficient PCB Assembly

Prices are for show only, please contact us for exact price.

Product Description

The YAMAHA YSM10 SMT Mounter with ATS offers exceptional precision and speed for Surface Mount Technology (SMT) applications. Designed for both high-mix and high-volume production, this SMT mounter is equipped with Automated Tool Setter (ATS) to optimize component placement accuracy and reduce setup time. The YSM10 handles a broad range of components, from fine-pitch chips to larger devices, with advanced vision systems ensuring high-quality placement every time. Ideal for industries such as electronics manufacturing, automotive, and telecommunications, the YSM10 enhances PCB assembly processes through its flexible feeder options and intuitive interface. The automated tool setting feature boosts efficiency by reducing downtime between changeovers, improving production throughput. Whether in high-mix or high-volume environments, the YAMAHA YSM10 guarantees optimal performance, reliability, and cost-effectiveness, making it a perfect choice for enhancing your SMT production line

Product Specifications

Model	YS12	YS24	YSM10
Applicable PCB	L510xW460mm to L50xW50mm	L50mm x W50mm to L700mm x W460mm	L 510 x W 460mm - L 50 x W 50mm
Mounting Capability	36,000CPH	72,000CPH	46,000CPH
Mounting Accuracy	+/-0.05mm/CHIP	+/-0.05mm ( + 3), +/-0.03mm (3)	0.035 mm (0.025 mm) Cpk>1.0 (3)
Number of component types	120 types(Max, 8mm tape reel conversion)	120 types (Max./8mm wide tape reel conversion)	15 types (sATS 15 equipment, Max, JEDEC)
Applicable components	0402(Metric base) to 32*mm components	0402 to 32x32mm MAX (Height 6.5mm or less)	03015-W 55 x L 100mm, H: 15mm or less
External Dimensions	L 1,254 x W 1,440 x H 1,445mm	L1,254x W1,687x H1,445mm	L 1,254 x W 1,440 x H 1,445mm

Precision and Versatility for PCB Assembly

The YAMAHA YSM10 SMT Mounter excels at placing a diverse component range, from tiny 0402 size chips up to large, odd-shaped parts and connectors. Its advanced vision system and high accuracy make it the ideal choice for manufacturing complex electronic boards that require both speed and precision.

Advanced Automation and User-Friendly Operation

Equipped with ATS (Auto Tray Sequencer) and original Yamaha software, the YSM10 streamlines setup and operation. Features like error traceback, production analytics, and intuitive touch panel controls enable smooth management and process optimization, supporting efficient high-volume assembly environments.

Robust Build, Safety, and Seamless Integration

Made from high-precision steel and industrial-grade composites, the YSM10 is engineered for durability and reliability. Integrated safety features-such as emergency stop, interlocks, and safety covers-protect operators. SMEMA/IPC compatibility and MES integration readiness ensure it fits smoothly into modern production lines.

FAQ's of YAMAHA YSM10 SMT Mounter with ATS High Precision Surface Mount Technology for Efficient PCB Assembly:

Q: How does the YAMAHA YSM10 SMT Mounter achieve high placement accuracy during assembly?

A: The YSM10 utilizes a high-speed multi-vision system, advanced camera-based recognition, and precise gantry movement to achieve a placement accuracy of 0.035 mm (Cpk 1.0) for chips. This ensures consistent and exact component placement across diverse PCB assembly tasks.

Q: What component sizes and types can the YSM10 SMT Mounter handle?

A: This mounter supports a wide variety of components, ranging from 0402 (01005) chips to large 45 x 100 mm parts, with a maximum height of 15 mm. It can mount chips, ICs, large connectors, and odd-shaped components, offering exceptional flexibility for manufacturers.

Q: When is the YSM10 SMT Mounter most beneficial for PCB manufacturing processes?

A: The YSM10 is especially beneficial in high-volume production environments requiring both speed and high accuracy, such as consumer electronics, industrial controls, or automotive PCBs. Its rapid placement speed (up to 46,000 CPH) and high feeder capacity optimize throughput.

Q: Where can the YAMAHA YSM10 be integrated within a production line?

A: The YSM10 is designed for seamless inline production and can be integrated into a wide range of SMT lines due to its flexible conveyor system, SMEMA/IPC interface support, and MES compatibility, making it suitable for both new setups and upgrades in Indian electronics factories.

Q: What is the process for using the YSM10's Auto Tray Sequencer (ATS) feature?

A: The ATS allows for automatic and efficient tray handling, minimizing manual intervention. Operators load trays into the system, and the YSM10's software manages component pick-up and placement, streamlining the entire mounting process for consistent productivity.

Q: How user-friendly is the operation and programming of the YSM10 SMT Mounter?

A: The YSM10 features Yamaha's original user-friendly software with a touch panel interface, making programming, monitoring, and troubleshooting straightforward even for operators with minimal experience. Error traceback and production analysis tools further simplify ongoing management.

Q: What benefits does the YSM10 offer in terms of safety and reliability?

A: With features like an emergency stop switch, interlock system, protective covers, and reliable steel construction, the YSM10 prioritizes operator safety. Its durability, advanced control systems, and robust build support consistent, long-term operation in demanding industrial environments.
