MQQLDV32-20- SMC Cylinder XM4-AXM4-A

MQQLDV32-20- SMC Cylinder XM4-AXM4-A Specification

Lubricating System
Oil-Free

Size
32 mm bore

Drive Type
Pneumatic

Usage & Applications
Factory Automation, Industrial Machinery, Material Handling

Features
Magnetic, Compact Design, Easy Mounting

Shape
Cylindrical

Diameter
32 mm

Surface Finish
Smooth/Matte

Noise Level
Low

Product Type
Pneumatic Cylinder

Material
Aluminum Alloy

Technology
Double Acting

Power Source
Compressed Air

Power
Manual / Pneumatic

Pressure
0.15~1.0 MPa

Surface Treatment
Anodized

Dimension (L*W*H)
32 mm bore x 20 mm stroke (cylinder only)

Weight
Approx. 0.32 kg

Color
Metallic Silver

Stroke Length
20 mm

Port Size
M5 x 0.8

Mounting Type
Basic, through hole and tapped

Model Number
MQQLDV32-20

Cushion Type
Rubber Cushion

Seal Material
High Durability NBR

End Cap Material
Aluminum

Actuation
Double Acting

Operating Temperature Range
-10C to +70C

Rod Type
Single Rod

MQQLDV32-20- SMC Cylinder XM4-AXM4-A Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
7

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

About MQQLDV32-20- SMC Cylinder XM4-AXM4-A

Prices are for show only, please contact us for exact price.

SMT Product List

X02G51112	FXED BLADE (PANASONK RL131)
N210056710AA	CUTTER(PANASONK RL131)
N644N919ME	CUPLINK(PANASONK AVK2B)
3087114001 / MSM082AJA	MOTOR MSM082AJA
N210192364AA / X02G52201	BACK UP PN(PANASONK RL131)
N644N1319	panasonic coupling
MRS18-DUL	Axial fans
N510002593AA	N510002593AA Panasonic driver

Durable and Reliable Construction

Crafted from high-grade anodized aluminum alloy, the MQQLDV32-20 cylinder ensures long-lasting performance even in demanding environments. Its high durability NBR seals and oil-free lubrication reduce maintenance needs, while the robust end caps enhance longevity. This makes it highly suitable for extended industrial use.

Precision and Versatility in Applications

Engineered with a compact, easy-to-mount design, the MQQLDV32-20 offers versatility across various sectors, including factory automation, material handling, and industrial machinery. The smooth operation and low noise output make it ideal for environments where precision and quiet performance are essential.

FAQ's of MQQLDV32-20- SMC Cylinder XM4-AXM4-A:

Q: How do I mount the MQQLDV32-20 SMC Cylinder XM4-AXM4-A?

A: This cylinder supports both through hole and tapped mounting types, making installation straightforward and flexible for a variety of machine configurations.

Q: What are the recommended operating conditions for this pneumatic cylinder?

A: The operating temperature range for the MQQLDV32-20 is -10C to +70C, and it can operate within a pressure range of 0.15 to 1.0 MPa, ensuring reliable performance in most industrial settings.

Q: When should the cylinder be used in industrial applications?

A: The MQQLDV32-20 is ideal for scenarios requiring compact, precise, and low-noise actuation, such as in factory automation lines, material handling setups, and lubrication systems.

Q: Where can the MQQLDV32-20 cylinder be applied most effectively?

A: It is particularly efficient in environments like industrial machinery, automation assemblies, and areas requiring quick, repetitive linear motion due to its magnetic and oil-free design.

Q: What are the key benefits of the high durability NBR seal material?

A: The NBR seals offer enhanced resistance to wear, extending the cylinder's service life and minimizing downtime caused by seal failures.

Q: How does the rubber cushion in the cylinder benefit my application?

A: The integrated rubber cushion absorbs impact at the stroke end, reducing noise and mechanical stress, which helps prolong the service life and ensures smoother operation.
